3D Printing Alloy Spherical Cobalt Powder Co CAS 7440-48-4

Overview Of 3D Printing Alloy Spherical Cobalt Powder

Spherical cobalt alloy powder mainly comprises cobalt (Co) and may contain other alloying elements to optimize prformance. The specific alloy composition depends on the manufacturer and application requirements. It has high density, melting point, good thermal stability and corrosion resistance, hardness, and excellent magnetic properties.

(3D Printing Alloy Spherical Cobalt Powder Co CAS 7440-48-4)





3D Printing Alloy Spherical Cobalt Powder Co

Features of 3D Printing Alloy Spherical Cobalt Powder

3D Printing Alloy Spherical Cobalt Powder Properties
Other Names	Cobalt Powder
CAS No.	N/A
Compound Formula	Co
Molecular Weight	N/A
Appearance	Gray metallic solid in various forms (ingot, tubing, pieces, powder)
Melting Point	N/A
Solubility in water	N/A
Density	NA
Purity	N/A
Particle Size	0-20μm, 15-45μm, 15-53μm, 53-105μm, 53-150μm, 105-250μm
Boling point	N/A
Specific Heat	N/A
Thermal Conductivity	N/A
Thermal Expansion	N/A
Young’s Modulus	N/A
Exact Mass	N/A
Monoisotopic Mass	N/A
3D Printing Alloy Spherical Cobalt Powder Health & Safety Information
Safety Warning	N/A
Hazard Statements	N/A
Flashing point	N/A
Hazard Codes	N/A
Risk Codes	N/A
Safety Statements	N/A
RTECS Number	N/A
Transport Information	N/A
WGK Germany	N/A

 Parameter table of 3D Printing Alloy Spherical Cobalt Powder

Here is a parameter table of 3D printing alloy spherical cobalt powder:

Parameter	Typical Value
Chemical Composition	Mainly cobalt; in CoCrMo alloy, Cr: 26.5 – 29%, Fe ≤ 0.6%, W: 7.0 – 9.0%, Mn ≤ 0.4%, Si: 1.2 – 1.9%, Co: Balance25
Purity	≥99.5% or ≥99.9%13
Particle Size	Common ranges are 0 – 15 μm, 15 – 53 μm, 45 – 105 μm, 75 – 150 μm245
Oxygen Content	≤200 ppm or ≤150 ppm25
Nitrogen Content	≤100 ppm25
Sphericity	≥98% or ≥70%
Flowability	≤18 s25
Apparent Density	≥4.2 g/cm³25
Tensile Strength	330 ± 50 MPa25
Yield Strength	220 ± 30 MPa25
Ductility	5 ± 1%25

Applications Of 3D Printing Alloy Spherical Cobalt Powder

The application fields of 3D printed alloy spherical cobalt powder are wide, mainly covering the following aspects:

 Aerospace field: Due to its high melting point, high density, and good thermal stability, cobalt alloys have become an ideal choice for high-temperature components in the aerospace industry. Cobalt powder can be used to print components of gas turbine engines, such as combustion chambers, turbine blades, etc.. It can withstand extremely high temperatures and mechanical stress.

Medical and dental fields: Cobalt alloy has good biocompatibility and corrosion resistance, so it is commonly applied to manufacture medical implants, such as artificial joints and dental implants. 3D-printed cobalt alloy components can accurately match the patient’s anatomical structure and improve surgical outcomes.

Energy sector: Cobalt alloys are used in the energy field to manufacture electrode materials for fuel and electrolytic cells. Their good conductivity and corrosion resista

  Applications of 3D Printing Alloy Spherical Cobalt Powder Co

 Electronic and Magnetic Materials: Cobalt is an important magnetic element. Therefore, cobalt alloy powder is also used to manufacture high-performance electronic devices and magnetic materials. 3D printing technology can precisely control the shape and structure of materials, thereby manufacturing components with excellent magnetic properties.

Tool and mold manufacturing:The high hardness and wear resistance of cobalt alloy make it ideal for manufacturing tools and molds. Through 3D printing technology, tools and molds with complex shapes and structures can be manufactured, improving production efficiency and product quality.

Research and Development: Spherical cobalt alloy powder is also commonly used in scientific research to study new materials, processes, and technologies. 3D printing technology makes it available to quickly manufacture the required samples and prototypes for experiments, accelerating the scientific research process.

 Production Method of 3D Printing Alloy Spherical Cobalt Powder

Gas Atomization

1. Raw Material Preparation: Select high-purity cobalt and other alloying elements according to the desired alloy composition. For example, if making a Co – Cr – Mo alloy powder, accurate amounts of cobalt, chromium, and molybdenum are weighed.
2. Melting: The raw materials are placed in a high-temperature melting furnace, such as an induction furnace. The stove is usually operated under an inert gas atmosphere (e.g., argon) to prevent oxidation of the metals. The temperature is raised above the melting point of the alloy, typically around 1400 – 1600 °C for cobalt-based alloys, to obtain a homogeneous molten metal.
3. Atomization: The molten metal is poured through a small nozzle at a controlled rate. High-pressure inert gas (such as argon) is then sprayed onto the molten metal stream. The high-velocity gas breaks the stream into tiny droplets. Due to surface tension, these droplets tend to form spherical shapes.
4. Solidification and Collection: The droplets solidify rapidly as they cool in the gas-filled chamber. The solidified spherical powder is collected at the bottom of the chamber. Then, it undergoes further processing, such as sieving, to obtain the desired particle size distribution.

Plasma Atomization

1. Material Feed: Cobalt or its alloy in the form of a rod or wire is fed into a plasma torch.
2. Plasma Melting and Atomization: The plasma torch generates a high-temperature plasma arc (temperatures can reach tens of thousands of degrees Celsius). The high-energy plasma melts the fed material. The molten metal is then atomized by the high-velocity plasma jet, breaking it into fine droplets.
3. Cooling and Collection: Similar to gas atomization, the droplets cool and solidify in a controlled environment to form a spherical powder. The powder is collected and may be post-processed to meet specific requirements.

Chemical Reduction Method

1. Solution Preparation: Cobalt salts (such as cobalt chloride or cobalt nitrate) are dissolved in a suitable solvent to form a homogeneous solution. Other alloying element salts can also be added if making an alloy powder.
2. Reduction Reaction: A reducing agent, such as sodium borohydride or hydrazine, is added to the solution. The reducing agent reacts with the cobalt ions in the solution, reducing them to metallic cobalt. Under proper reaction conditions, the cobalt atoms aggregate to form spherical particles.
3. Separation and Purification: The formed cobalt powder is separated from the solution through filtration or centrifugation. It is then washed and dried to remove impurities and obtain pure spherical cobalt powder. However, this method may have limitations in achieving large-scale production and high-purity powder compared to the physical atomization methods.

Company Profile

RBOSCHCO is a trusted global chemical material supplier & manufacturer with over 12-year-experience in providing super high-quality chemicals and nanomaterials, including boride powder, nitride powder, graphite powder, sulfide powder, 3D printing powder, etc.The company has a professional technical department and Quality Supervision Department, a well-equipped laboratory, and equipped with advanced testing equipment and after-sales customer service center.If you are looking for high-quality 3D Printing Alloy Spherical Cobalt Powder Co, please feel free to contact us or click on the needed products to send an inquiry.

 Storage Condition of 3D Printing Alloy Spherical Cobalt Powder

1) Store in a dry environment at room temperature.

2) Avoid damp and high temperature.

3) Use immediately after opening the inner packing bag.

Payment Term

L/C, T/T, Western Union, Paypal, Credit Card etc.

Shipment Term

By sea, by air, by express, as customers request.



5 FAQs of 3D Printing Alloy Spherical Cobalt Powder

Q1

What is spherical cobalt powder?

Answer: Spherical cobalt powder is a cobalt based alloy powder used for 3D printing, characterized by powder particles being spherical or approximately spherical. This shape helps improve the powder’s flowability, bulk density, and printing quality.



Q2

What is the future development trend of spherical cobalt powder printing?

Answer: With the continuous progress of 3D printing technology and the optimization of cobalt alloy powder performance, spherical cobalt powder printing is expected to achieve higher printing speed, lower cost, and better material performance. In addition, it is possible to explore the combined use with other materials to expand the application field further.



Q3

Why choose spherical cobalt powder for 3D printing?

Answer: Due to its good fluidity, uniformity, and compact stacking properties, spherical cobalt powder helps improve the interlayer bonding strength and the density of printed parts during the 3D printing process. In addition, spherical particles can reduce powder blockage and wear during printing, improving printing efficiency.



Q4

What is the 3D printing process for spherical cobalt powder?

Answer: During the 3D printing process, spherical cobalt powder is laid on the printing bed and then selectively melted by laser or electron beam to construct the object layer by layer. The melted powder particles solidify after cooling to form the required components.



Q5

What are the application areas of spherical cobalt powder printed components?

Answer: Spherical cobalt powder printed components are widely used in aerospace, medical dentistry, energy, electronic, magnetic materials, and other fields. For example, they can manufacture components for gas turbine engines, artificial joints, fuel cell electrodes, electronic devices, and magnetic materials.
